Quick Detail:

No length or row limit for marking content
QR code (10mm*10mm) marking could reach the speed of 600 pcs/min
Used for constant or variable speed production line, checking the speed in real time to ensure the quality.
Range of Application
Widely used in production lines for tobacco, wine, food, beverage, medicine, cooking tools' serial number, date, QR code, vector file, image file etc.

Description:

• DB25 socket to connect IPG YLP and YLPM laser module via 25-pin cable directly.
• Support IPG,RAYCUS,V-GEN,JPT,MAX PHOTONICS,MANLIGHT,QUANTEL laser type.
• 24 routes general digital signals(TTL compatible ), 16 general input signals(TTL compatible In0-In13, XORG0(IN14), YORG0(IN15)),8 general output signals(TTL compatible),Out4-7 can be configured as OC outputs or TTL outputs
• Compatible with USB2.0 specifications.
• Mark-on-fly: encoder can be connected to the board to measure the fly speed .
• Power supply:+-5V/3A
• Dimensions: 167mm*125.5mm*23

Applicable scope:

• Laser Marking
• Laser Engraving
• Drilling circuit board with holes
• Cutting cloth
• Cutting paper
• Laser marking on metal

Function:

• Fly marking
• Ruler mark
• 4 kinds of Hatch
• Two axis control
• Multi-head
• Vision mark
