    High Speed Laser Scanning Equipment , Durable Red Focus Laser Scanning Head

    Ask Lasest Price
    Brand Name : BJJCZ
    Model Number : scan head-RED
    Certification : ce
    Price : 450-1000$
    Payment Terms : T/T
    Supply Ability : 1000set
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    High Speed Laser Scanning Equipment , Durable Red Focus Laser Scanning Head

    Quick Detail:

    GO7-YAG-10-RED scan head is 2D scan system and support 10mm input laser beam ,suitable for laser marking, welding, 3D ,etc.

    High Speed Laser Scanning Equipment , Durable Red Focus Laser Scanning HeadHigh Speed Laser Scanning Equipment , Durable Red Focus Laser Scanning Head

    Description:

    The product support XY2-100 protocol, and support digital signal command to work with BJJCZ laser control board.there are two red point light in the scan head .them can indicate the laser focus and show center position.


    High Speed Laser Scanning Equipment , Durable Red Focus Laser Scanning Head


    Work temperature25℃±10℃
    The wave length of the mirror355/532/1064/10600nm
    Interface protocolXY2-100
    Power supply

    3A

    ±15V DC

    Positioning speed3m/s
    Marking speed1.5m/s
    Nonlinear read3.5mrad
    Scan angle±0.35rad
    Aperture10mm
    Tracking error0.25ms
    8 hours drift<30mrad
    Zero drift<12nrad/k
    Gain drift<50ppm/k

    Applications:

    Laser marking ;

    Laser welding ;

    Specifications:

    Support XY2-100 protocol ;

    Support 10mm input laser beam;

    Work with BJJCZ laser control board ;

    Support double red point light to indicate the laser focus and the position;

    Competitive Advantage:
