    Yag Laser Scan Head ± 15v 5a Adopt Xy2-100 Protocol For 3d Laser Marking

    Ask Lasest Price
    Brand Name : BJJCZ
    Model Number : 3D
    Price : 2000-10000$
    Payment Terms : T/T
    Supply Ability : 1000set
    Delivery Time : 5-15days
    • Product Details
    • Company Profile

    Yag Laser Scan Head ± 15v 5a Adopt Xy2-100 Protocol For 3d Laser Marking

    3D SCAN HEAD / YAG Laser scan head / 3D Laser Marking / 3D Scanner

    Quick Detail:

    The scanner is designed for 3D laser marking. Adopt XY2-100 protocol, work with EZCAD3 software and DLC board.

    The variation limit of Z range can be reached within 170.


    Description:

    The scanner is designed for 3D laser marking. Adopt XY2-100 protocol, work with EZCAD3 software and DLC board.

    The variation limit of Z range can be reached within 170.


    Electrical param

    Power

    support

    voltage±15VSignal typedigitalxy2-100 Standard
    current5A
    fluctuation≤200mvFeature deflection±0.393 rad
    noise≤0.5%DC to 30 MHzResolution12μrad
    Rated temperature25℃±10℃Reproducibility<25μrad
    Store temperature25℃±10℃Gain drift80ppm/K
    Humidity≤80% non-condensingCompensation drift0.02°/K
    More than 8 hours long-term drift<0.3mrad
    Machinery Param
    Incident aperture6mmClear aperture10mm
    Beam offset12.54mmweight——
    Mirror Param
    Wave length1064nmFlatnessλ/4
    CoatingSilver IPMax.laser power70W/cm²
    Mirror size10mm
    Reflection rate>98%
    Z-Axis Param
    Wave length1064nmMax.laser power60W/cm²(No air cooling)
    Gain multiple1.67
    Z-focus length±35mmField size174mm*174mm

    Yag Laser Scan Head ± 15v 5a Adopt Xy2-100 Protocol For 3d Laser MarkingYag Laser Scan Head ± 15v 5a Adopt Xy2-100 Protocol For 3d Laser Marking
