Poplar low power nanosecond integrated laser/UV Laser Marking
machine parts
Quick Detail:
One of the main products of Huaray Laser Nanosecond product line,
the quality verification of more than 10,000 installed capacity in
the world, integrated design of the whole machine, simple
integration, various performance indicators have reached the
international leading level, good beam quality, with online
monitoring function, can be realized Real-time monitoring and
remote diagnosis is a highly reliable light source for precision
machining
Applicable scope:
3C industry, white goods, electrical enclosures, food packaging,
ultra-thin metal processing, metal or non-metal surface coating
removal(for example laser
engraving machine for glassware and laser
marking plastic)
Function:
Integrated design, inert gas protection, air filtration cycle,
alarm mechanism
Specifications:
| SPECIFICATSPECIFICATIONSIONS | Poplar-355-3 | Poplar-355-5 | Poplar-532-10 |
| Fundamental Center Wavelength | 355nm | 355nm | 532nm |
| Output Power and Energy | >3W, >75µJ@50kHz | >5W, >125µJ@50kHz | >10W, >200µJ@50kHz |
| Repetition Rate | 20kHz-200kHz | 20kHz-200kHz | 20kHz-200kHz |
| Pulse Width | 20±2ns@50kHz | 16±2ns@50kHz | <18ns@50kHz |
| Spatial Mode | TEM00(M2≤1.2) | TEM00(M2≤1.2) | TEM00(M2≤1.2) |
| Beam Divergence | ≤1mrad ≤2mrad | ≤1mrad ≤2mrad | ≤2mrad |
| Astigmatism | <0.2 | <0.2 | <0.3 |
| Beam Circularity | ≥90% | ≥90% | ≥90% |
| Polarization Ratio | >100:1 | >100:1 | >100:1 |
| Polarization Direction | Horizontal | Horizontal | Vertical |
| Beam Pointing Stability | <25μrad/°C | <25μrad/°C | <25μrad/°C |
| Pulse Energy Stability | ≤3%RMS | ≤3%RMS | ≤3%RMS |
| Power Stability | ≤3%RMS | ≤3%RMS | ≤3%RMS |
| Long-term Pointing Stability | <25μrad/°C | <25μrad/°C | <25μrad/°C |
| External Comms | RS-232 | RS-232 | RS-232 |
| Beam Diameter, 0.3m in Front of Laser | ＜8mm | ＜8mm | ≤2mm |
| Working Material | Nd:YVO4 | Nd:YVO4 | Nd:YVO4 |
| Warm-up Time | <15min | <15min | <15min |
| Operating Temperature | +10 to +35℃ | +10 to +35℃ | +10 to +35℃ |
| Operating Humidity | <65% | <65% | <65% |
| Non-Operation(Storage) Temperature | -10 to +45℃ | -10 to +45℃ | -10 to +45℃ |
| Shipping Temperature(Non-condensing) | -10 to +45℃ | -10 to +45℃ | -10 to +45℃ |
| Cooling | Water | Water | Water |
| Power Consumption (VAC) | 110/220V AC, 50/60Hz, 500W | 110/220V AC, 50/60Hz, 500W | 110/220V AC, 50/60Hz, 600W |
| Classification | Class 4 | Class 4 | Class 4 |
Competitive Advantage:
1. Integrated design of the whole machine, simple integration
2. All performance indicators have reached the international
leading level and high reliability.
3. online monitoring function, real-time monitoring and remote
diagnosis
4. the beam quality is good
