    Wood Marking Laser Cutter Control Board 16 General Input Signals Design

    Ask Lasest Price
    Brand Name : BJJCZ
    Model Number : BJJCZ-SZ-B-H1
    Certification : CE
    Price : negotiated
    Payment Terms : T/T, Western Union
    Supply Ability : 1000SET
    Delivery Time : 3-5 WORK DAYS
    • Product Details
    • Company Profile

    Wood Marking Laser Cutter Control Board 16 General Input Signals Design

    Wood Marking Laser Cutter Control Board 16 General Input Signals Design

    CON3: DB9 flying standard interface
    Pin.NameDescription
    1IN8Input port 8
    2,6IN9+,IN9-Input port 9 positive
    3,7BCODEP/ BCODENInput port 9 negative
    4,5ACODEP/ACODENEncoder input B+/B-
    8VCC+5V output
    9GNDGround


    Features:
    1. 16 general input signals (TTL compatible): In0-In13, XORG0(IN14), YORG0(IN15).
    2. 8 general output signals (TTL compatible): Out0-7 coming out of Con5. Out0-3 are TTL outputs. Out4-7 can be configured as OC outputs or TTL outputs.
    3. Laser Err signal: this signal will be activated when there is an error occurs in the laser, OC output.
    4. Remark function: this function is used to remark what ever is in the memory f the board, especially conveient for high speed marking on same pattern.
    5. Compatible with USB2.0 specifications.
    6. 16 general input signals (TTL compatible), 8 general input signals (TTL compatible)
    7. Using USB2.0 specifications


    Applications:


    ModelCO2
    Connect MethodUSB2.0
    Galvo control signalCan be directly connected to a universal digital galvao
    Number of Input Ports16 universal input ports
    Number of Output Ports14 way TTL/ OC
    Remark SignalCache content repeated engraving
    Extended AxisSupport for 2 extension axis
    Flight MarkingSupport
    Multi-head CarvingSupport
    Software Second DevelopmentSupport
    Suitable LaserCO2 / YAG / UV Laser
    Applicable MaterialGlass, Plastic, Wood, Rubber, Paper
    Support Operating SystemXP WIN7 WIN8 WIN10 32/64 Bit System
    Built-in Encryption ChipSupport
    Power Supply5V 3A
