Plastic Marking Laser Module Card Blue Color JCZ Laser Marking
Board
Description:
Quick Details
Place of Origin:
China
Brand Name:
BJJCZ
Model Number:
LMCV4-DIGIT
Product name:
digital laser control board
Application:
CO2 laser marking/engraving
Wavelength:
10600/1064nm
main featurel
Galvo control signal is digital, which can be connect to most
scanhead directly.l
on-the-fly marking feature. A encoder can be used to surveillance
the pipeline speedreal-timely.l
Multiple system function. One computer can control up to 8 control
board to mark differentpattern simultaneouslyl
Extension axis(step motor or sever motor): two set of
direction/pulse signal can be used tocontrol 2 step(server)
motors.l
16 general input signals(TTL campatible): In0-In13, XORG0(IN14),
YORG0(IN15).l
14 general output signals(TTL campatible): Out0-7 coming out of
Con5. Out8-13 coming outof CON2. Out0 - 3 ,out8 and out13 are TTL
outputs. Out4-7 can be configured as OCoutput or TTL output by
jumpers. Out 9-12 are OC outputs.l
ReMark(REpeat MARKing signal): in the case of high speed marking of
a same pattern, afoot pedal can be connected to this pin. If some
variables are in the pattern or the pattern istoo big for the cache
in board, the foot pedal can be only connect to general input
pins.l
Laser signal: we provide both high level effective and low level
effective signals.l
PWM signal: both differential and TTL signal is provided.l
A specified red light pointer signal is now added.l
Two analog signal that control power/frequency is now addedl
Using USB2.0 specification
Applications:
| Model | Co2 |
| Connect Method | USB2.0 |
| Galvo control signal | Can be directly connected to a universal digital galvao |
| Number of Input Ports | 16 universal input ports |
| Number of Output Ports | 14 way TTL/ OC |
| Remark Signal | Cache content repeated engraving |
| Extended Axis | Support for 2 extension axis |
| Flight Marking | Support |
| Multi-head Carving | Support |
| Software Second Development | Support |
| Suitable Laser | CO2 / YAG / UV Laser |
| Applicable Material | Glass, Plastic, Wood, Rubber, Paper |
| Support Operating System | XP WIN7 WIN8 WIN10 32/64 Bit System |
| Built-in Encryption Chip | Support |
| Power Supply | 5V 3A |
