Fiber laser marking machine -Metal laser marking machine

Advantages of fiber laser coding machine/fiber laser engraver
The marking software has powerful functions and can be compatible with files of CorelDRAW, AutoCAD, Photoshop, etc.; it supports PLT, PCX, DXF, BMP, etc., and can directly use SHX and TTF font library; it supports automatic coding, printing serial number, batch number, date, barcode, two-dimensional code, automatic skip number, etc
2. It adopts an integrated whole structure, equipped with automatic focusing system, and the operation process is humanized.
3. The original imported isolator is used to protect the fiber laser window and enhance the stability and laser life.
4. No maintenance, long service life, small size, suitable for harsh environment.
5. The processing speed is fast, which is 2-3 times of the traditional marking machine.
6. With high electro-optic conversion efficiency, the power consumption of the whole machine is less than 500W, which is 1 / 10 of the lamp pumped solid-state laser marking machine, which greatly saves energy consumption.
7. The output quality of the laser beam is not better than that of the traditional laser beam with a diameter of 20um. The divergence angle is 1 / 4 of the diode pumped laser. It is especially suitable for fine and precise marking.

Characteristics of portable fiber laser marking machine
Laser output power
≤10W
≤20W
Laser wavelength
1064nm
Beam quality M2
≤1.4
≤1.8
Laser Q-switched frequency
20kHz~100kHz
20kHz~200kHz
Standard carving range
110mm × 110mm (optional)
Carving depth
≤1mm
≤2mm
Overall power
400W
500W
Small line width
0.01mm
Repeatability accuracy
±0.0001mm
Electricity demand
Single phase AC 90-250v / 50Hz 5A
Single phase AC 90-250v / 50Hz 10A
Carving speed
≤15000/s
≤18000/s
System dimensions
800mm×250mm×500mm
Cooling system
Wind cooling
