    10w 30w 40w 355nm Femtosecond Fiber Laser

    Ask Lasest Price
    Price : negotiated
    Payment Terms : T/T, Western Union
    Supply Ability : 1000set
    Delivery Time : 3-5 work days
    • Product Details
    • Company Profile

    10w 30w 40w 355nm Femtosecond Fiber Laser

    Huaray Laser (A invested company of JCZ) is developing and manufacturing reliable femtosecond ultrafast laser HR-Femto series of industrial-level fiber femtosecond lasers. They are categorized into the HR-Femto-10 (10 μJ), HR-Femto-50 (50 μJ), and HR-Femto-50HE (80 μJ) series, which are verified, highly reliable, and can be used 24/7. Laser pulse widths of <350 fs or <350 fs to 5 ps are adjustable. Greenlight wavelengths can be output by using a harmonic generator (SHG).


    The HR-Femto-50 series of industrial femtosecond lasers are proven, highly reliable, and are designed for 24/7 operation. The laser supports >60 W power at 1035 nm wavelength, >80 μJ single pulse energy, adjustable pulse widths from

    Main Features:
    - Up to 60 W average power
    - Single pulse energy up to 80 μJ
    - - 1 Hz - 1 MHz Adjustable Repeat Frequency
    - Supports multiple Burst Mode combinations
    - Includes pulse selector for on-demand pulse splitting
    - Rugged, industrialized one-piece design
    - Optional SHG module to support green light output

    Application Field:

    • - Drilling and cutting of hard and brittle materials
    • Glass Welding
    • Micro fabrication of metal materials
    • Composite film material processing
    • New Energy Materials Processing
    • Processing and handling of polymers
    • Medical device manufacturing
    • Fiber Optic Grating Writing
    • Glass Laser Engraving

    10w 30w 40w 355nm Femtosecond Fiber Laser

    SPECIFICATIONSHR-Femto-IR-50-40HR-Femto-IR-80-60HR-Femto-GN-25-20HR-Femto-GN-30-24
    Center Wavelength1035 nm1035 nm517nm517nm
    Average Power40 W60 W20 W24 W
    Pulse Energy50 μJ @ 800 kHz80 μJ @ 750 kHz25 μJ @ 800 kHz30 μJ @750 kHz
    Pulse Duration
    Burst Energy200 μJ320 μJ100 μJ120 μJ
    Peak Power>140 MW>220 MW>70 MW>110 MW
    Repetition RateSingle shot to 1 MHzSingle shot to 1 MHzSingle shot to 1 MHzSingle shot to 1 MHz
    Beam QualityM2≤1.3M2≤1.3M2≤1.3M2≤1.3
    Beam Divergence
    Beam Circularity≥90%≥90%≥90%≥90%
    Beam Diameter3 ±1 mm, 1/e23 ±1 mm, 1/e23 ±1 mm, 1/e24 ±2 mm, 1/e2
    Polarization StateLinearLinearLinearLinear
    Pulse Stability<2% RMS<2% RMS<2% RMS<2% RMS
    Power Stability<2% RMS<2% RMS<2% RMS<2% RMS
    Operating Temp10 to 30 °C10 to 30 °C10 to 30 °C10 to 30 °C
